NSD Absocoder NCW-3DHPRV2 Specifications & Instruction Manual page 8

2. MODEL SELECTION WHEN ORDERING
The following figure indicates the connection configuration of NCW-3DHPR.
Before ordering, refer to the connection configuration and model list. Please prepare by customer except (1) to (3) in
the connection configuration.
● Connection configuration
PLC
Master
PROFIBUS-DP
(1) Converter
Slave
Slave
Slave
Power Supply
+24V
0V
Ground
(3) Extension sensor cable (2) ABSOCODER sensor
Connector VRE-16TS100
type
B
R
2
