NSD Absocoder NCW-3DHPRV2 Specifications & Instruction Manual page 10

3. SPECIFICATIONS
3-1. Converter Specifications
(1) General specification
Items
Power supply voltage
Power consumption
Insulation resistance
Withstand voltage
Vibration resistance
Ambient operating temperature
Ambient operating humidity
Ambient operating environment
Ambient storage temperature
Grounding
Construction
Outside dimension (mm)
Mass
(2) Performance specification
Items
Applicable sensor
Total number of divisions
Number of effective bits
Position detection format
Output code
Number of detection axes
Position data sampling time
Error detection
Auxiliary functions
Monitor LED
Front panel operation
Applicable standard
24VDC±10% (including ripple)
10W or less
20 M-Ohms or more between external DC power terminals and ground
(by 500 VDC insulation resistance tester)
500 VAC, 60Hz for 1 minute between external DC power terminals and
ground
2
20m/s 10 to 500Hz, 10cycles of 5 minutes in 3 directions,
conforms to JIS C 0040 standard
0 to +55°C (No freezing)
20 to 90 %RH (No condensation)
Free from corrosive gases and excessive dust
-25 to +70℃
Must be securely grounded (ground resistance of 100 ohm or less)
Book-shelf type within enclosure, DIN rail mountable
39(W) x 155(H) x 93(D) Refer to dimensions for details.
Approx. 0.4kg
Specifications
VRE-16TS100
16
65536(2 )
16 (D0 to D15)
Absolute format
Binary code
2
0.2ms
- PROFIBUS-DP power supply error
- Sensor error
- Memory error
- Watchdog timer error
Preset function
PON: Power ON
DTEX: PROFIBUS-DP data refresh in progress
RDY: Converter normal (ready for operation)
PRE1/PRE2: Preset operation (zero set)
ME: Memory error
SE1/SE2: Sensor error
Position data: D0-D23
Preset data: D0-D23
Converter's diagnosis data
Parameter data
Error clear: CLR
Zero set: ZPS1/ZPS2
LED display selecting: DISP SEL
PROFIBUS-DP node address setting: NODE x16, x1
CE Marking (EMC directive)
4
Specifications
Notes
LED display changes
by selecting the
DISP. SEL switch.
