9-2. Preset Data (Output Data: Master → Slave)
The master can change the position data to any desired value by performing the preset function using Output Data.
The changed position data is stored in the converter's non-volatile memory. Therefore, there is no need to do the
preset function each time the power is turned on.
byte
bit7
offset
PRESET
0
1
1 0
PRD15
2
(MSB)
3 PRD7
PRESET
4
2
5 0
PRD15
6
(MSB)
7 PRD7
Signal name
PRD0-15 Preset data
PRESET1 Axis-1 preset signal
PRESET2 Axis-2 preset signal
CLR Error clear signal
*1: The PRESET1/2 signal should be set to "0" if the position data is the same as the preset data. Although the
position data is changed when the PRESET1/2 signal changes from "0" to "1", the position data received by the
master remains the same as the preset data while the PRESET1/2 signal is "1". When the PRESET1/2 signal
changes to "0", the position data at that point can be read.
(When PRESET1/2 signal is changed to 1 by the PLC pulse instruction, "1" of the PRESET1/2 signal might not
be sent because of the relation between PLC scan time and Output Data update time of the PROFIBUS-DP
communication.)
*2: When the PRESET1/2 signal changes from "1" to "0", the converter cannot receive another PRESET1/2 signal
for a period of 100 ms.
NOTE
The preset function is disabled when a "sensor error" (SE) occurs.
bit6 bit5
CLR 0
0 0
PRD14 PRD13 PRD12
PRD6 PRD5 PRD4
CLR 0
0 0
PRD14 PRD13 PRD12
PRD6 PRD5 PRD4
Name
The position data can be changed to any desired value (Preset
data: PRD0-15) by setting PRESET1/PRESET2 to "1". *1, *2
Preset data range: 0 ~ FFFFH (0 ~ 65535)
Number of effective bits: PRD0 - PRD15
The following error can be cleared by setting this bit to "1".
•Converter diagnosis data error (PRFPF, ME)
bit4 bit3 bit2
0 0 0
0 0 0
PRD11 PRD10
PRD3 PRD2
0 0 0
0 0 0
PRD11 PRD10
PRD3 PRD2
26
bit1 bit0
0 0
0 0
PRD9 PRD8
PRD0
PRD1
（LSB）
0 0
0 0
PRD9 PRD8
PRD0
PRD1
（LSB）
Description
Axis-1
preset data
Axis-2
preset data
