NSD Absocoder NCW-3DHPRV2 Specifications & Instruction Manual page 48

11-2. ABSOCODER Sensor Check List
● Applicable ABSOCODER sensor models
VRE-16TS100
● Connection configuration
ABSOCODER sensor
● Connector appearance and pin position
● Connector pin position and standard coil resistance ranges (at 25℃)
Check position
A1, A2, B1, B2
Wiring
Pin No. Pin No.
color
1 Brown
2 Red
3 Orange
4
－
5 Green
6 Blue
7 Violet
8 Gray
9
－
10
－
11 Shield
12
－
The above standard coil resistance ranges are referential data to assist wiring disconnection diagnosis and are not
product specification values. There may be no wiring disconnection even when the resistance measurement is out of
the standard resistance range.
A1
A2
View
A1, B1
B3 Signal
names
Wiring
color
1 Brown U
2 Red V
3 Orange W
4
－ －
5 Green OUT1＋
6 Blue OUT1－
7 Violet OUT2＋
8 Gray OUT2－
－ － －
－ － －
9 Shield Shield
－
－ －
Extension sensor cable
B1
B2
B3
Standard coil resistance [Ω]
VRE-16TS100
115 to 135
18 to 28
25 to 35
42
Converter
B3
B3
B3
View
