NSD Absocoder NCW-3DHPRV2 Specifications & Instruction Manual page 49

● Circuit resistance check
[Measurement method]
Measure resistance at Point A or B using a circuit tester or other appropriate device.
Have Point A connected to measure at Point B.
If the connector is off, identify the line by the wiring color.
[Check details]
Refer to the previous page for the connector pin number.
Check position
Between brown and red
Between brown and orange
Between red and orange
Between green and blue
Between violet and gray
*1: If checks are done at Point B, the measurement value is [Standard coil resistance + extension sensor
cable resistance.
Extension sensor cable resistance value
The resistance value of the NSD special cable is 0.2Ω/m (loop resistance).
Consider resistance variations due to temperature, which, relative to the standard temperature (25
increases 0.4% when the temperature rises 1
● Insulation check
[Measurement method]
Measure using a 500 VDC insulation tester.
[Check details]
Refer to the previous page for the connector pin number.
Between brown and, green, violet, shield
Between green and, violet, shield
Between violet and shield
Between frame and each wire or shield
Note
1. Make sure to disconnect the ABSOCODER sensor from the converter before carrying out insulation checks.
2. If there is a risk that energization may cause damages to the electronic circuits in and around the machine,
remove the ABSOCODER sensor from the machine.
3. After completing the checks, short-circuit between the pins to discharge remaining voltage before connecting
the ABSOCODER sensor to the converter.
Criterion
The measured value
should be in the range of
the standard coil resistance.
*1
Check position
Check position
Between brown and, green, violet, shield
Between green and, violet, shield
Between violet and shield
Between frame and each wire or shield
o
C and decreases 0.4% when the temperature falls 1
Criterion
10MΩ or more
43
Criterion
∞
o
C),
o
C.
