11-1-1. Flowchart when Position Data doesn't Change
Position data doesn't change.
Has an error status
occurred?
Is the sensor
moving?
Is the cable connecting
the NCW-3DHPR to the
sensor OK?
Is Preset signal
OFF?
Is operation normal
when the sensor is
replaced?
The NCW-3DHPR hardware problem is likely.
Contact your service representative immediately,
providing him with details of the problem.
YES
NO
NO
YES
NO
YES
NO
YES
YES
NO
Check the error status to determine the cause.
Move the ABSOCODER sensor.
Verify that the ABSOCODER sensor and converter
are properly wired (refer to section 7 for connection
details).
Set Preset signal OFF.
The sensor hardware problem is likely.
Contact your service representative
immediately, providing him with details of the
problem.
