NSD ABSOCODER NCW-3DHPNL8 Specifications & Instruction Manual page 69

APPENDIX 1-2. Product Operation & Error History
The cumulative energization time, operation, and error history of NCW-3DHPN can be checked.
Index Name
Power Distribution Time
0x3000
Event Log
0x3100
Access Data
Read Write Type
○ - UDINT
○ - 256
(8[32])
62
Description
Indicates the cumulative energization time of NCW-3DHPN.
(Unit: sec)
Indicates the operation and error information histories of
NCW-3DHPN.
The history is stored in nonvolatile memory. (Max.32 histories)
Arrangement contents
Name
Data Type
DWORD
Message
code
UDINT
Event
occurrence
time
Remarks
History message code
Refer to next page.
Time when an event
occurs
