NSD ABSOCODER NCW-3DHPNL8 Specifications & Instruction Manual page 12

3. SPECIFICATIONS
3-1. Converter Specifications
(1) General specification
Items
Power supply voltage
Power consumption
Insulation resistance
Withstand voltage
Vibration resistance
Ambient operating temperature
Ambient operating humidity
Ambient operating environment
Ambient storage temperature
Grounding
Construction
Outside dimension (mm)
Mass
(2) Performance specification
Items
Converter model
Applicable sensor
Resolution
Total number of divisions 8192×2048
Position detection format Semi-absolute format
Output code
Number of detection
axes
Position data update
interval
Error detection
Auxiliary functions
Monitor LED
Front panel operation
Applicable standard
24VDC±10% (including ripple)
10W or less
20 M-Ohms or more between external DC power terminals and ground
(by 500 VDC insulation resistance tester)
500 VAC, 60Hz for 1 minute between external DC power terminals and ground
20m/s 10 to 500Hz, 10cycles of 5 minutes in 3 directions,
2
conforms to JIS C 0040 standard
0 to +55°C (No freezing)
20 to 90 %RH (No condensation)
Free from corrosive gases and excessive dust
-25 to +70°C
Must be securely grounded (ground resistance of 100 ohm or less)
Book-shelf type within enclosure, DIN rail mountable
39(W) x 155(H) x 93(D) Refer to dimensions for details.
Approx. 0.4kg
Specifications
NCW-3DHPNL8
VLS-8SM20 VLS-8SM14
1μm(8.192mm/8192 divisions)
Binary code
2
Minimum 2ms
Update time : By PROFINET communication cycle setting
Sensor error, Memory error, Watchdog timer error,
Internal I/F error
Preset function
MS: Module status
NS: Network status
L/A1/L/A2: Communication status
PON: Power ON
RDY: Converter normal
PR1/PR2: Preset operation (Current position setting)
ME: Memory error
SE1/SE2: Sensor error
Position data: D0 to D23
Preset data: D0 to D23
Previous preset data: D0 to D23
Converter's diagnosis data
Parameter
Communication diagnostic data
LED display selecting: DISP SEL
CE Marking (EMC directive)
Specifications
VLS-8SM14S
5
Notes
PROFINET
Communication
monitor
LED display changes
by selecting the DISP.
SEL switch.
Rotary switch
