8. NOMENCLATURE
8-1. Part Identification
Power terminal block
Axis-1 sensor connector
Axis-2 sensor connector
(M4 screw)
MAC address
E8:8E:60
xx:xx:xx
Monitor LEDs
Selection switch of the Monitor LED
display contents
Ethernet port 1 (LINK1)
(RJ45)
Ethernet port 2 (LINK2)
(RJ45)
