NSD ABSOCODER NCW-3DHPNL8 Specifications & Instruction Manual page 43

(6) "Assign PROFINET device name" window is appears on the screen.
Click "Update list" button.
The devices which can be changed the name are listed.
(7) Select the converter whose device name is changed, and click the "Assign name" button.
The device name is changed to the name which is set in procedure (4).
"OK" is displayed on the "Status" of the selected converter when changing of the device name is succeeded.
After the change, click "Close" button for closing the window.
(6)
36
(6) Device list
(7)
(7)
(7)
