NSD ABSOCODER NCW-3DHPNL8 Specifications & Instruction Manual page 15

(2) VLS-8SM14, VLS-8SM14S
Items
Model
Max. detection stroke
Absolute detection range
Resolution
Linearity error
Mass
Sliding resistance
Permissible mechanical speed
Ambient temperature
Ambient operating humidity
Vibration resistance
Shock resistance
Protection rating
Interconnecting cable
Max. sensor Standard cable
cable length
Robotic cable
Head
Surface
Rod
Head
Material
Rod
Head 1.1+0.07 x [cable length(m)] kg
Rod
Operating
Storage
2.0 x 10
Specifications
VLS-8SM14
200 mm
8.192 mm
1μm(8.192mm/8192)
Customer's Special Specifications
0.0012 x ([rod length (mm)] kg
15 N or less (1.5kgf or less)
1000 mm/s
-10 to +80℃
-10 to +80℃
m/s (20G) 200Hz up/down 4h, forward/back 2h,
2 2
conforms to JIS D 1601 standard
4.9 x 10 m/s (500G) 0.5ms, up/down x 3 times,
3 2
conforms to JIS C 5026 standard
IP67, conforms to JEM1030 standard
2・5・10・20m
3S-S 200m
3S-RBT 100m
Electroless nickel plated
Hard chromium electro plated
Steel
Steel
8
VLS-8SM14S
0.8+0.07 x [cable length(m)] kg
－
