13. ABSOCODER SENSOR CHECK LIST
●Applicable ABSOCODER sensor models
VLS-8SM20
VLS-8SM14
VLS-8SM14S
● Connection configuration
ABSOCODER sensor
● Connector appearance and pin position
● Connector pin position and standard coil resistance ranges (at 25℃)
Check position
A1, A2, B1, B2
Wiring
Pin No.
color
1 Brown
2 Red
3 Orange
4
－
5 Green
6 Blue
7
－
8
－
9
－
10
－
11 Shield
12
－
The standard coil resistance ranges shown below are referential data to assist wiring disconnection
diagnosis and are not product specification values. There may be no wiring disconnection even when the
resistance measurement is out of the standard resistance range.
A1
A2
View
A1, B1
B3 Signal
names
Wiring
Pin No.
color
1 Brown
2 Red
3 Orange
4
－
5 Green OUT＋
6 Blue OUT－
7
－
8
－
9 Shield Shield
－ －
－ －
－ －
Extension sensor cable
B1
B2
B3
Standard coil resistance [Ω]
VLS-8SM20
U
V 114 to 154
W
－ －
162 to 202
－
－
－
－
－
57
Converter
B3
B3
B3
View
VLS-8SM14
VLS-8SM14S
132 to 152
－
150 to 180
