9-6. Set the Communication Cycle
Sets the communication cycle between the PLC and converter.
A default value of the communication cycle is set to "2ms (minimum value)".
Change the communication cycle in the following window if it needed to change.
(1) In the "Device view" tab, display "Update time" from General->PROFINET Interface->Advanced options->Real
time settings->IO cycle.
(2) In the default setting, "Calculate update time automatically" is checked.
Check "Set update time manually", and select the update time when changing it.
38
(1)
(2)
