9. PROFINET COMMUNICATION SETUP
9-1. Procedure Before the Operation
Indicates procedure before the operation.
Start setup
Preparation
Set the network configuration
Set NameOfStation
Set the IP address
Set the communication cycle
Set the sensor parameter
Create of the NCW-3DHPN
tag table
Download the Device
description file
Check the positon data
Finish setup
-------- Refer to section 9-2.
Download the GSDML file (XML file) from NSD web site.
URL: www.nsdcorp.co.jp
-------- Refer to section 9-3.
Set the network configuration of NCW-3DHPN.
-------- Refer to section 9-4.
Set the device name.
-------- Refer to section 9-5.
Set the IP address.
-------- Refer to section 9-6.
Set the communication cycle between the PLC and NCW-3DHPN.
-------- Refer to section 9-7.
Set the sensor parameter of NCW-3DHPN.
-------- Refer to section 9-8.
Create the I/O data tag for using NCW-3DHPN's I/O data by the sequence
program of PLC.
-------- Refer to section 9-9.
Download the Device description file to the PLC.
-------- Refer to section 9-10.
Check the position data is counted correctly.
