NSD ABSOCODER NCW-3DHPNL8 Specifications & Instruction Manual page 11

● Model List
◆Converter
No. Model
NCW-3DHPNL8
①
◆ABSOCODER sensor
No. Items
Linear type
(2) ABSOCODER
sensor
◆Extension sensor cable
No. Model
3S-S-0144-[L]
3S-RBT-0144-[L]
3S-URT-0144-[L]
3S-S-4344-[L]
3S-RBT-4344-[L]
3S-URT-4344-[L]
3S-HRT-5152-[L]
3S-S-0190-[L]
3S-RBT-0190-[L]
(3)
3S-URT-0190-[L]
3S-S-9044-[L]
3S-RBT-9044-[L]
3S-URT-9044-[L]
3S-HRT-9052-[L]
3S-S-9090-[L]
3S-RBT-9090-[L]
3S-URT-9090-[L]
3S-HRT-9090-[L]
[L]: Specify the cable length (m) that you need.
◆GSDML
No.
File name:
(4)
GSDML-V***-NSD_Corporation-NCW3D_PN-********xml
For linear type ABSOCODER sensor
Position data 24-bit binary code output
Models
VLS-8SM20-[1]FA[2][L]
VLS-8SM20-[1]LA[2][L]
VLS-8SM14-[1]FB[2][L]
VLS-8SM14S-[1]FB[2][L]
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Heat-resistant robotic cable
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Heat-resistant robotic cable
Standard cable
Robotic cable
Semi-heat-resistant robotic cable
Heat-resistant robotic cable
Model
Description
[1]: Stroke
VLS-8SM20:
Flange-mount
50, 100, 150, 200, 250, 300, 350
type
VLS-8SM14(S):
50, 100, 150, 200
Base-mount
[2]: Connector type
type
B: Standard connector
(NJW-2012PM8, manufacturer:
Nanaboshi Electric Mfg.Co,Ltd.)
Flange-mount
Contact your NSD representative for
type
VLS-8SM14 and VLS-8SM14S.
R: Crimping terminals (R1.25-4)
Z: No connector
Flange-mount
type
[L]: Interconnecting sensor cable
length (m): 2, 5,10, 20
Description
Download it from NSD website.
4
Descriptions
Standard connector
Crimping terminal
Description
