10 Decommissioning the Product

Danger to life due to electric shock
Lethal voltages are present at the connection point of the utility grid.
• Disconnect the connection point from the utility grid using the separator (e.g. miniature
circuit breaker).
Procedure:
1. Pull the two-pole power supply unit plug out of the jack X1 on the Data Manager.
2. Unlock all RJ45 connectors of the network cable and pull out of the network ports X14, X15
and X16 of the Data Manager.
3. Pull all connectors out of the sockets X3 to X13 on the Data Manager.
4. If mounted on a DIN rail: to detach the
Data Manager from the DIN rail, unlock both lower
base latches using a suitable tool. Tilt the lower
edge of the Data Manager forwards and lift it up
and off the DIN rail.
5. If mounted on a wall: remove the screws from the base latches and remove the
Data Manager.
Also see:
• Disposal ⇒ page 76
