6. In case of an external setpoint, activate Source for external setpoint and select the
applicable options.
7. Activate Behavior in case of setpoint change.
8. Select Implementation with PT1 element and enter the value 0.2 s in the field Setting
time.
9. Select Gradient and enter the value 500%/s for Max. increase of the default value and
Max. decrease of the default value.
10. Click on [Next].
11. Click on [Save].
Also see:
• Register Devices ⇒ page 58
8.8.4 Configure additional direct seller's specifications for the
country data set.
During device registration, the required country data sets are selected for the detected devices. To
achieve the correct control speed for the country data set, you need to make additional settings.
Requirements:
☐ The user interface must be open and you must be logged in as Installer or Administrator.
Procedure:
1. Select the system in the focus navigation.
2. Select the menu item Grid management service in the menu Configuration.
3. Select the button Configuration & activation in the Active and reactive power row.
4. Open the configuration wizard for Direct seller settings under Active power.
5. Under the Direct seller settings, activate the Source for external setpoint and select one
of the available options.
6. Activate Behavior in case of setpoint change.
7. Select Implementation with PT1 element and enter the value 0.2 s in the field Setting
time.
8. Select Gradient and enter the value 500%/s for Max. increase of the default value and
Max. decrease of the default value.
9. Click on [Next].
10. Click on [Save].
Also see:
• Register Devices ⇒ page 58
