1. Specifications
1.3. Performance Specifications of Driver
Table 1.4. TS Type Driver and TH Type Driver Performance Specifications
Item
Number of Controlled Axis
Angle Setting Unit
Angle Setting Minimum Unit
Speed Setting Unit
Speed Setting Range
Number of Indexes
Maximum Instruction Value
Timer
Programming Language
Programming Method
Operation Mode
Coordinate
Acceleration Curve
Status Display
Motion Display
Communication Interface
CC-Link Communication
Function
(Ver. 1.10, 2 stations
occupied, remote device
station)
Program Capacity
Electronic Thermal
[SMF-2008]
1-axis, 540,672 pulses/rotation
° (degree), pulse, and number of indexes
0.001*, 1 pulse (= about 2.4 sec [0.00067 deg.])
0.01 to 100 sec/0.11 to 300 rpm
7 digits input ±9,999,999
0.01 to 99.99sec
Data setting through RS-232C port using PC
Auto, single block, MDI, jog, servo OFF Pulse string input,
network operation mode
Absolute and incremental
Modified sine (MS), Modified constant velocity (MC, MC2)
Modified trapezoid (MT), Trapecloid (TR)
LED power lamp display
7-segment LED (2 digits)
Meets RS-232C specification
Home positioning instruction, reset, start, stop, continuous
rotation stop, emergency stop, answer, position deviation
counter reset, program number selection, jog, brake
release, servo ON, program number setting, ready return
Alarm 1 and 2, positioning completion, in-position, standby
for start input, M code 8 points, output during indexing 1•2,
home position output, M code strobe, segment position
strobe, servo status, ready output
<NC program>
About 6,000 characters (256 pcs.)
Protects the actuator from being overheated.
― 1-5 ―
Description
sec, rpm
1 to 255
NC language
<Five types>
<Input>
<Output>
<Point table>
64 points
