CKD ABSODEX AX Series Instruction Manual page 7

Table 1.3. XS Type Driver General Specifications
Item
Main
Power
Supply
voltage
Control
Frequency
Rated input current
Input: Phase number
Output voltage
Output frequency
Rated output current
Output: Phase number
Power system
Mass
Outside diameter size
Configuration
Operating Ambient
Temperature Range
Operating Relative
Humidity Range
Storage Ambient
Temperature Range
Storage Relative
Humidity Range
Atmosphere
Anti-noise
Anti-vibration
Altitude
Protection
1-phase or 3-phase: 200 VAC ± 10% to
230 VAC ± 10% (standard)
1-phase 100 VAC ± 10% to 115 VAC ± 10% (J1: option)
1-phase 200 VAC ± 10% to 230 VAC ± 10% (standard)
1-phase 100 VAC ± 10% to 115 VAC ± 10% (J1: option)
1-phase or 3-phase
W75×H220×D160
Open modular type (driver, and controller)
20 to 90%RH (No condensation allowed)
20 to 90%RH (No condensation allowed)
Free from corrosive gases, and dust
1,000 V (P-P), pulse width 1μsec, startup 1nsec
IP2X (CN4 and CN5 are excluded)
― 1-4 ―
Description
50/60 Hz
1.8 A
0 to 230 V
0 to 50 Hz
1.9 A
3-phase
TN, TT, IT
About 1.6 kg
0 to 50ºC
-20 to 65ºC
2
4.9 m/s
1,000 m or less
1. Specifications
[SMF-2008]
