Summary of Contents for CKD AFB-RB Series
- Page 1 New Products Active Fine Buffer AFB-RB Series Buffer & Rotation Operation Ideal for Alignments Built-in battery-less absolute sensor CC-1415A...
-
Page 2: Case Study
The motor and fine buffer are integrated for buffer and rotation operations. All-in-one unit makes the Case Study manifold configuration compact and lightweight. Soft touch Layered transport Compact camera and lens modular assembly Using the fine buffer (magnetic spring cushioning mechanism) enables uniform pressure without relying on stroke. -
Page 3: Specifications
Active Fine Buffer AFB-RB Series Load capacity: 50g Specifications Item AFB-RB Buffer force 0.5±0.2, 1.0±0.2 (Selection method) Buffer force change rate ±15% or less Stroke 3, 6 (Selection method) Ambient temperature °C 10 to 40 Storage ambient temperature °C 0 to 50 (no condensation) Rotation runout 0.01 Repeatability... -
Page 4: How To Order
AFB-RB Series How to order How to order AFB RB Description Code Buffer force (N) Buffer force Model No. Stroke length (mm) Stroke Mounted motor specification Note Mounted motor specification Oriental Motor's two-phase stepping motor (Motor Model No.: PKP213D05) [Example of model No.] Oriental Motor's five-phase stepping motor (Motor Model No.: PK513PB) AFB-RB1006A... - Page 5 AFB-RB Series Dimensions AFB-RB*** M5 depth 4 Stepper motor (Vacuum port) 4-M2.5 spot face hole Cable length 300 (motor type A, C) ø2.5 (Vacuum flow path) 17.5 C0.3 (115.5) 8(sensor dog mounting range) ø3 ( +0.02 )depth 3 AFB-RB**D (AZ motor) M5 depth 4 AZ motor (Vacuum port)
-
Page 6: Safety Precautions
If the product specified herein fails for reasons attributable to CKD within the warranty period specified above, CKD will promptly provide a replacement for the faulty product or a part thereof or repair the faulty product at one of CKD’s facilities free of charge. - Page 7 Pneumatic components Safety Precautions Be sure to read this section before use. Refer to "Pneumatic, Vacuum and Auxiliary Components No. CB-024SA" for general precautions. Product-specific cautions: Active Fine Buffer AFB-RB Series Design/selection DANGER CAUTION Do not use in places where dangerous goods such as ignitable The load (jig and suctioned workpiece) on the shaft substances, inflammable substances or explosives are present.
- Page 8 Fully understand contents before starting use. Do not hold the product's movable parts or cables during transportation and installation. Consult with CKD when using this unit with the This may lead to injury or disconnection. method above. Do not install in places where large vibration or impact is transmitted.
-
Page 9: Use/Maintenance
Consign it to a specialized waste disposal company for processing. Warranty when exporting to foreign countries (1) CKD will repair products returned to the CKD plant or a company/ factory designated by CKD. Compensation of construction and return shipment expenses are excluded. -
Page 10: Related Products
Related products Catalog No. CC-796A Vacuum system equipment SELVACS Compact design Each component has been compactly designed to save space. Wide model variation Extensive model series and variations handle a wide range of fields and applications. Unitized/modularized The ejector system/vacuum pump system which form the core are unitized and modularized, designed to save space and increase ease of use. - Page 11 Revision details AZ Motor option added Safety precautions changed 2022.10...
