5 SET MODE
(13) RTTY tone settings (branch).'t-PAIr'
Push [SET] to enter sub setting display.
e RTTY tone "rity-t"
The MARK tone of RTTY mode can be selected
from high tone (2125 Hz) or low tone (1615 Hz).
2125 Hz mark (default)
e RTTY shift width "rtty-s"
The shift width can be selected from 170 Hz, 200 Hz
and 425 Hz.
rk EY-S
170 Hz shift width (default)
(14) Optional filters (branch) 'oPt-FIL"
When an optional filter is installed, this selection is
necessary, otherwise, the filters cannot be selected.
Push [SET] to enter sub setting display.
e 9 MHz SSB narrow filter "LSB -9-"
When the optional FL-223 is installed, select "yES."
FL-223 is not installed. (default)
FL-223 is installed.
e 9 MHz CW narrow filter "CW -9-"
When the optional FL-101 is installed, select "yES."
CW
mec SÉ
FL-101 is not installed. (default)
e RTTY data tone "dAtA-t"
The MARK tone of RTTY DATA mode can be
selected from 1070 Hz, 1275 Hz, 1600 Hz, 2025 Hz,
2110 Hz and 2125 Hz.
2025 Hz data tone (default) |
e Front panel data input "dAtA-Fr"
The DATA modes inhibit the input from the MIC}
connector. It can be accepted if desired.
Front panel data input inhibits (default)
GC
Y NOTE: Push [ENT] to exit the sub setting display.
e 9 MHz AM medium/SSB wide filter "AM -9-"
When the optional FL-102 is installed, select "yES."
FL-102 is not installed. (default)
e 455 kHz SSB narrow filter "LSB 455"
When the optional FL-222 is installed, select "yES."
LSB
mo 45
FL-222 is not installed. (default)
e 455 kHz CW narrow filter "CW 455"
When the optional FL-53A is installed, select "YES."
5
CW
Ci
FL-53A is not installed. (default)
Y NOTE: Push [ENT] to exit the sub setting display.
