Installation and Assembly
4.
i
4.1
Fig. 1 IF2030/ENETIP dimensional drawing, dimensions in mm (inches)
IF2030/ENETIP
Installation and Assembly
Ensure careful handling during installation and operation.
Installation of the Interface Module
+0,35
22.6
-0,3
(.89)
TS35
Top-hat rail
+0,6
107
(4.21)
-0,4
113.7 (4.48)
