Heating insert

Introduction
The Ignite and Ignite+ systems can be operated with metal sleeves called heating
inserts, which are placed around the syringe. The heating inserts ensure good thermal
contact between the syringe heaters of the instrument and differently sized syringes.
Heating inserts are specific to the instrument. See
on page 130
Ignite heating insert compatibility
Each Ignite heating insert is labeled with a size. The table below shows which heating
insert size is appropriate for each compatible syringe manufacturer.
Syringe
BD
size
1 mL 1 mL
2 mL X
2.5 mL X
3 mL 3 mL
5 mL 5 mL
10 mL 10 mL
X: Syringe not supported by Ignite instrument
NanoAssemblr Ignite and Ignite+ Operating Instructions NIN1134 AA
for more information. The image below shows an Ignite heating insert.
B Braun B Braun
Injekt Omnifix
1 mL 1 mL
X X
X X
X 3 mL - O
5 mL 5 mL
10 mL 10 mL
Section 9.5 Ordering information,
Heating insert size
Terumo Shinva
Ande
1 mL 3 mL
X 3 mL
X X
3 mL 3 mL
5 mL - T 5 mL
10 mL 10 mL
3 System description
3.5 Accessories
3.5.1 Heating insert
KDL WEGO
1 mL X
3 mL 3 mL
X X
X X
5 mL 5 mL
10 mL 10 mL
KOVAX
3 mL
X
X
X
X
X
