3.4.1

Main menu

Overview
The operation and user interface is identical for the Ignite and Ignite+ instruments.
Both instruments have a touchscreen user interface mounted on the front of the main
instrument.
The illustration below shows the main menu on the instrument.
Part
1
2
3
4
NanoAssemblr Ignite and Ignite+ Operating Instructions NIN1134 AA
1
3
4
5
6
7
Name
Information bar
Heater control
icon
Cartridge indicator
Recipes
2
Description
Includes menu title, and current date and time
Shows the status of the heating system
Shows the status of the cartridge in the instru-
ment
Enables user to create, edit, and store formula-
tions providing convenient access to frequently
used formulations
3 System description
3.4 User interface
3.4.1 Main menu
