Shenchen Peristaltic Pump
C
800.00
275.86 rpm
Volume
Time
Current
Speed/Flow Rate Display: Under the flow rate mode, display the current set up
flow rate, the motor speed display at the C frame. Under the
rotating speed mode, display the current set up speed, flow rate
display at the C frame. Click A to amend the flow rate or speed.
When fixed time and volume function turn on, A is forbidden, not
allowed to amend the flow rate or speed.
Real-time Dynamic Display：Display the current running state.
Real-time Parameter Display：Display the current running state and set up
parameter. When the fixed volume measurement turn on, display
the fixed volume measurement parameter; when the fixed time and
volume function turn on, display the fixed time and volume
parameter. When these two functions turn off, display the
parameter is all 0.
Set Parameter Display：Display the fixed volume measurement, fixed time and
volume state information, the model of pump head and tube size.
Date and Time Display： Display the current data and time, you can change it in the
system setting. When it display an alarm clock on the right side, it
B A
ml/min
/
Setting
50.00 ml
2.00 s
0.00 ml
Volume
- 4 -
D E
2012-3-15 8:45:05 AM
Fixed volume On
Dispensing Off
Pump Head YZ1515x
Tubing Size 17#
F G H
Calibration Date&Time
I J K
Dispensing Timing
LabV Series
