Shenchen Peristaltic Pump
Pulse mode: the pump working status change once when
receive one pulse signa(
Level mode: when high level, the pump running; when low
level the pump stop running.
Set up the external control mode in the setting interface, turn on
the correspond external control function, external control signal
is active.
④、 R/S 1 External control signal input terminal: Passive signal input.
Pulse mode: R/S 1 short connect with GD1 and then disconnect, the
pump start running. Short connect and disconnect again, the pump stop
running.
Level mode: R/S 1 short connect with GD1, the pump running; when
disconnect, the pump stop running.
This terminal can connect with passive switch and foot pedal. In the
external control setting interface to set the active of this terminal, the
foot pedal option.
⑤、 The motor working status output terminal:
Output motor working status as below:
rising edge effectively
- 21 -
LabV Series
)l.
