Shenchen Peristaltic Pump
External Control Interface Instruction:
External control interface as below:
①. Analog signal input terminal: External control setting interface,
choose the' Analog Signal' and turn on the 'Ext. Speed'. Control the motor
speed from 0 rpm to 600rpm through analog signal.
0-10V
0-5V
4-20mA
I-/V-
+5V
GD1
GD2
NC
CW/CCW
R/S 2
R/S 1
COM
OUT1
OUT2
- 19 -
LabV Series
GND
TXD
RXD
GD1
A+
B-
