Shenchen Peristaltic Pump
Boot into the
main interface
Click the setting button,
choose pump head and
tubing size, choose
working mode: Flow rate
Click the Volume button,
turn on the fixed volume
function, the volume range
is 0.01mL-9999L
Click the flow rate
display area in main
interface, input flow
rate
Note: Flow rate calibration process please refer the flow rate calibration
interface instruction.
3、Dispensing
Boot into
the main
interface
Click the setting button,
choose pump head and
tubing size, choose
working mode: Flow rate
Click Dispensing button,
turn on the Dispensing
function, set the
parameters
Click the Calibration
button, calibrate the set up
volume, the process refer
to the calibration interface
instruction
Note: Flow rate calibration process please refer the flow rate calibration
interface instruction.
4、Timer Start And Stop Function
Click the Calibration
button,the default
calibration time is 60s,
you can change it
before calibration
Back to the main
interface after finish
the calibration, click
the start key
The pump display the current flow
volume and running time, when the
flow volume reach set up value, the
pump will stop automatically. Click
the start key, start the volume
measurement again
The flow rate can be
changed during the pump
working, the measurement
accuracy will be lower
after change the flow rate
Back to the main inter-
face after finish
calibration, click start
key start working
The pump display the current
volume and countdown time,
when the time is out, the pump
stop working automatically,
click the start key, start next
dispensing
The flow rate can be
adjust during the pump
working, improve the
accuracy
- 15 -
Click here input flow rate
Display the
dynamic
working state
Display the
current rotating
speed and state
Display the
dynamic
working state
Display the
current rotating
speed and state
LabV Series
The set up volume
The current
running time
The volume has
been transferred
The set up volume
The current
countdown time
The volume has
been transferred
