filling liquid.
CW/CCW Button: Press this button, the motor will change running direction.
When the pump working with fixed volume measurement function or
fixed time and volume function, this button does not work.
Start Button: Press this button, the motor start running. When fixed volume
measurement function or fixed time and volume function turn on, press
this button, the pump will start work with the function.

LabV Series Operation Interface Structure:

LabV Series Operation Interface Instruction
1. Boot Interface:
After power on the system, enter the welcome interface, choose system language,
Chinese/English. If do not choose, it will enter the English main interface after 2.5
seconds automatically.
2. Main Interface:
Main Interface Composition as below:
- 3 -
