Shenchen Peristaltic Pump
the top right corner of main interface.
Click Set Date button, come out the Set year numeric keypad, the range of the
year is 1970-2099. After set up the year, then set the month and date.
Click Set Time button, come out the numeric keypad, set the hour, minute and
second.
11、Fixed Volume Measurement Interface:
Fixed Volume Measurement Interface as below:
Fixed volume function turned on,flow rate is 800.00mL/min
After turn on this function, the peristaltic pump will measure the volume
automatically, when the volume reach set up volume, the pump will stop
working automatically. The flow rate can be changed during the pump working.
Click the Fixed Volume button, set ON to turn on this function. Click Set Volume,
to input volume, the unit can be mL or L, range is 0.01mL to 9999L. The
prompting frame display the needed time to finish the volume with set up flow
rate. The maximum time is 9999min, when more than 9999min, the system will
warn.
12、Dispensing Interface:
Dispensing Interface as below:

Fixed volume

Finished need 0.75 minutes.
- 12 -
Volume
600.00
mL
OK
