Shenchen Peristaltic Pump
LabV Series
Set baud rate
Communication protocol
9600
ShenChen
RS232/RS485
ON/OFF
RS485
Slave No.
01
OK
Click Setting button in the main interface, then click Communication button to
enter Communications Settings interface.
This pump support MODBUS--RTU Mode.
Please
select
baud
rates
and
communication interface (RS485/RS232). Click Slave No. button to enter peristaltic
pump address No.(range:1-32 ), select communication enable is ON. Then this
pump can be communication with master, receiving master signal.
NOTE: Peristaltic pump only under communication control when in the main
interface, it's out of communication control when in other interface.
9、Flow Rate Calibration Interface:
Flow Rate Calibration Interface as below:
- 9 -
