Shenchen Precision Pump LabV Series Manual

Hide thumbs Also See for LabV Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Shenchen Precision Pump
Manual of LabV Series
Baoding Shenchen Precision Pump Co.,Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LabV Series and is the answer not in the manual?

Questions and answers

Related Manuals for Shenchen Precision Pump LabV Series

Summary of Contents for Shenchen Precision Pump LabV Series

  • Page 1 Shenchen Precision Pump Manual of LabV Series Baoding Shenchen Precision Pump Co.,Ltd...
  • Page 2 Note: Please read the manual carefully before operating the product.  Warning:  Connect the power cord to the wall socket directly, and avoid using the extended electric wire.  If the power cord or plug had wear and other damage, please disconnect the plug.

  • Page 3: Table Of Contents

    Catalogue 1. Product Introduction ....................- 1 - 2. Product Appearance .....................- 1 - 3. Keyboard Instruction ................... - 2 - 4. Operation Interface Structure ................- 3 - 5. Main Functions Operation Process ..............- 15 - 6. External Control Interface Instruction ...............- 19 - 7.

  • Page 4: Product Introduction

    LabV Series 1. Product Introduction LabV series product are the flow measurement type intelligent peristaltic pump, 4.3 inch color touch screen control; Animation shows working state; flow data, setting parameters and system settings are displayed in the same screen. Intelligent calibration and online micro adjusting function;...

  • Page 5: Keyboard Instruction

    Shenchen Pump LabV Series E——External Control Port F——Built-in fuse 3. Keyboard Instruction Stop Button: Press stop button, pump stops working. Forbidden buttons in the  main interface can be used. Keep pressing the button and turn on the pump power supply, that will initialize the pump and all the parameters will be lost.

  • Page 6: Operation Interface Structure

    Shenchen Pump LabV Series 4. Operation Interface Structure LabV Series Operation Interface Instruction 4.1 Booting Interface After turn on the system, enter the welcome interface, click anywhere or wait for 2.5 seconds it will enter the English main operation interface automatically.
  • Page 7 Shenchen Pump LabV Series Speed/Flow Rate Display: In the flow rate mode, displays the current flow rate, the motor speed is displayed at the C frame. In the speed mode, displays the current set up speed, flow rate is displayed at the C frame. Click A to amend the flow rate or speed.
  • Page 8 Shenchen Pump LabV Series 4.3 Numeric Keypad Input Interface Numeric keypad input interface as below: Input Information Display: The information displayed is the current operation object. Input Data Display: Display the current input data, range is 0.01-9999. Unit Display: Display input units when input flow rate or volume.
  • Page 9 Shenchen Pump LabV Series 4.4 The Basic Configuration Interface The basic configuration interface: Click the Pump Head and Tubing Size to choose the pump head and tubing. Reference flow rate displays the maximum and minimum flow rate with the current pump head and tubing.
  • Page 10 Shenchen Pump LabV Series EasypumpI use as two channels, or with 3 or 4 EasypumpI pump heads, need to select single pump head EasypumpI, as in below picture: 4.5 Back Suction Angle Interface The back suction angle interface as below: Click the System Settings button in the main interface, then click Back Suction button to enter the back suction angle setting interface.
  • Page 11 Shenchen Pump LabV Series 4.6 External Setting Interface External Setting Interface as below: Click System Settings button in the main interface, then click External control to enter External Settings interface. There are two types of signals for external control motor start/stop and direction: Level mode and Pulse mode.
  • Page 12 Shenchen Pump LabV Series 4.7 External Speed Control Setting Interface External Speed Control Setting Interface as below: Click System Settings button in the main interface, then click External Speed Control button to enter External Speed Control Settings interface. According with external input signal to set the analog signal: 0-5V, 0-10V or 4-20mA.
  • Page 13 Shenchen Pump LabV Series 4.8 Communication Setting Interface Click System Settings button in the main interface, then click Communication button to enter Communication Settings interface. This pump support Modbus--RTU Mode. Please select baud rates and communication interface (RS485/RS232). Click Slave No. button to enter peristaltic pump address No.(range:1-32 ), select communication enable is ON.
  • Page 14 Shenchen Pump LabV Series 4.9 Flow Rate Calibration Interface Flow Rate Calibration Interface as below: The top left corner displays the function, when fixed volume measurement turn on, displays fixed volume; When dispensing turned on, displays dispensing. Others displays transferring mode.
  • Page 15 Shenchen Pump LabV Series CAL button, prompt the calibration is successful. If request higher accuracy, you can click Add and Dec button to micro adjust the flow rate, to reach high accuracy transferring and dispensing. Click Reset button, restore to the factory default calibration parameters.
  • Page 16 Shenchen Pump LabV Series In that interface, you can set the current date and time, it will display at the top right corner. Click Set Date button, come out the Set year numeric keypad, the range of the year is 1970-2099. After set up the year, then set the month and date.
  • Page 17 Shenchen Pump LabV Series 4.12 Dispensing Interface Dispensing Interface as below: After turn on this function, the pump will enter dispensing mode. Peristaltic pump transfer fixed volume in fixed time, transfer times are the Repeat times, click suspend time button then input suspend time, prompt box display current diameter, after click the OK button, click the start button, the pump begin dispensing according to the diameter.

  • Page 18: Main Functions Operation Process

    Shenchen Pump LabV Series 4.13 Timer Start and Stop Interface Start pump and stop time can be set in any time on this function. After the current time reaches to the setting time, it will automatically execute start/stop function or stop the motor.
  • Page 19 Shenchen Pump LabV Series 5.2 Fixed Volume Measurement Function Note: Please refer the flow rate calibration interface instruction for flow rate calibration process. 5.3 Dispensing Note: Please refer the flow rate calibration interface instruction for flow rate calibration process. - 16 -...
  • Page 20 Shenchen Pump LabV Series 5.4 Timer Start And Stop Function Under the flow rate transferring mode, set the pump start at 8:30 a.m. from Monday to Friday, stop at 5:30 p.m., the process as below: - 17 -...
  • Page 21 Shenchen Pump LabV Series Click Start Time, set the start time is 8:30 a.m., turn the button to ON. Click Custom, come out the repeat date window, as below: - 18 -...

  • Page 22: External Control Interface Instruction

    Shenchen Pump LabV Series 6. External Control Interface Instruction External control interface as below: Analog signal input terminal: Choose the External speed control signal and turn on the Ext. Speed in external control setting interface, control the motor speed from 0 rpm to maximum speed through analog signal.
  • Page 23 Shenchen Pump LabV Series 0-10V: 0V to 10V voltage signal input terminal. 0-5V: 0V to 5V voltage signal input terminal. 4-20mA: 4mA to 20mA current signal input terminal. I_/V_: Analog signal negative terminal. Notice: Please do not connect 0-10V signal to 0-5V terminal or 4-20mA input terminal.
  • Page 24 Shenchen Pump LabV Series In Pulse mode: Short circuited K2 then disconnect, the motor starts running. Short circuited and disconnect again, motor stops running. (Under transferring and dispensing modes, current working has been stopped. Under fixed volume measurement mode, current working has been paused. Disconnect after short circuit again, it will continue to work);...
  • Page 25 Shenchen Pump LabV Series The motor working status output terminal: Output motor working status as below: If connect with relays, when the motor runs, K1 connect; when the motor stops running, the K1 disconnect. Communication interface RS232 communication interface: Choose RS232 in the Communication setting interface, this terminal is active.

  • Page 26: Technical Specification

    Shenchen Pump LabV Series RS485 Communication Interface: Choose RS485 in the communication setting interface, this terminal is active. GD1: RS485 signal ground A+: Connect RS485 A+ terminal B-: Connect RS485 B- terminal Note: No matter choose RS232 or RS485, the communication protocol is standard MODBUS protocol.
  • Page 27 Shenchen Pump LabV Series LabV3, LabV3-II, 0.1-350rpm LabV3-III LabV6, LabV6-III 0.1-600rpm LabV1, LabV1-II, LabV3, LabV3-II, <50W LabV6 Power consumption LabV1-III, LabV3-III, <80W LabV6-III LabV1, LabV1-II, LabV3, LabV3-II, Stepper motor LabV6 Motor type LabV1-III, LabV3-III, Closed loop stepping motor LabV6-III Temperature 0-40℃...

  • Page 28: Function And Features

    Shenchen Pump LabV Series 8. Function and Features 4.3 inch color touch screen control, animation shows working state, the flow  volume and motor speed are displayed in the same screen. Intelligent calibration function, it can calibrate the flow rate and dispensing ...

  • Page 29: Dimension Drawing

    Shenchen Pump LabV Series 9. Dimension Drawing Unit: (mm) 9.1 Single pump head YZ1515x pump head MC pump head - 26 -...
  • Page 30 Shenchen Pump LabV Series AMC pump head EasyPump pump head - 27 -...
  • Page 31 Shenchen Pump LabV Series 9.2 LabV series product LabV+YZ15 pump head Note: For each additional pump head in series, the longitudinal dimension shall be increased by 55mm. LabV + MC pump head Note: For each additional channel, the longitudinal dimension shall be increased by 10mm.
  • Page 32 Shenchen Pump LabV Series LabV + AMC pump head Note:For each additional channel, the longitudinal dimension shall be increased by 10mm. LabV+EasyPump pump head Note:For each additional pump head in series, the longitudinal dimension shall be increased by 61mm. - 29 -...

  • Page 33: Maintenance

    Shenchen Pump LabV Series 10. Maintenance Check the running status of machine before starting it, normal operation can  be put into use. Check for leakage, and correct fault which can be appeared.  Clean liquid overflowed from the pump in time.

  • Page 34: Warranty And After-Sales Service

    Shenchen Pump LabV Series 11. Warranty and After-sales Service We support 3 years warranty for the pumps, subject to the exceptions below. Our company shall not be liable for any loss, damage, or expense directly or indirectly related to or arising out of the improper use of its products. This warranty does not obligate our company to bear any costs of removal, installation, transportation, or other charges which may arise in connection with a warranty claim.
  • Page 36 MADE IN CHINA Baoding Shenchen Precision Pump Co., Ltd. Address: No.103, Building 2, ZhiDian Industrial Park, FuXing East Road 999, Baoding, China. 071000 Tel: 0086-312-5958380 Fax: 0086-312- 6780636 Website: www.good-pump.com Email: info@good-pump.com...

This manual is also suitable for:

Labv1Labv3Labv6Labv1-iiLabv3-iiLabv1-iii ... Show all
