Shenchen Peristaltic Pump
⑦、 RS485 Communication Interface: Choose RS485 in the
communication setting interface, this terminal is active.
GD1: RS485 signal interface
A+: Connect RS485 A+ terminal
B-: Connect RS485 B- terminal
Instruction: No matter choose RS232 or RS485, the communication
protocol is standard MODBUS protocol.
- 23 -
LabV Series
