Shenchen Peristaltic Pump
Boot into
the main
interface
Click the setting
button, choose pump
head and tubing size,
choose working mode:
Flow rate mode
Click Timing button,
set the start time and
over time, set the
repeat times
Under the flow rate transferring mode, set the pump start at 8:30 a.m. from
Monday to Friday, stop at 5:30 p.m., the process as below:
Start time
Switch for the timer start
Timer start repeat date
Click Start Time, set the start time is 8:30 a.m., turn the button to ON.
Click Custom, come out the repeat date window, as below:
On the top right corner of the
main interface, means the timer
start and stop function is turn
on, when reach the set up time,
the pump will start or stop
automatically
During the pump working,
you also can set the start and
stop time. When fixed
volume or dispensing
function is turn on, the timer
stop function is forbidden
StartTime
08:30:00 AM
Once
Custom
- 16 -
The timer start and stop
01:30:00 PM 01:30:00 PM
OverTime
Over time
05:30:00 PM
Switch for the timer stop
Timer stop repeat date
Once
Custom
OK
LabV Series
function is turn on
The current time
