- Page 1 MADE IN CHINA Baoding Shenchen Precision Pump Co., Ltd. Address: No.103, Building 2, ZhiDian Industrial Park, FuXing East Road 999, Baoding, China. 071000 Tel: 0086-312-5958380 Fax: 0086-312- 6780636 Website: www.good-pump.com Email: info@good-pump.com...
- Page 2 Shenchen Precision Pump Manual of M6 Series Baoding Shenchen Precision Pump Co., Ltd.
- Page 3 Note: Please read the manual carefully before operating the product. Warning: Connect the power cord directly to the wall socket and avoid using extention electric wire. If the power cord or plug have wear or other damage, please disconnect the ...
- Page 4 Catalogue 1. Product Instruction ..................... - 1 - 2. Product Appearance and Interface Instruction ............ - 1 - 3. Operation Panel Instruction ................- 2 - 4. External Control Interface Instruction ..............- 4 - 5. Technical Specifications ..................- 8 - 6.
- Page 5 Shenchen Pump M6 series Product Instruction M6 series pump speed range is 0.1-600 rpm, flow rate range is 0.211~12000 ml/min. Adjust speed manually or automatically through external control interface. Power-down memory function, when re-power on, the pump will work with previous status.
- Page 6 Shenchen Pump M6 series Operation Panel Instruction Left/right switch Digital knob Start/stop Start/Stop Left Right External control External control External control External control start/stop direction speed www.good-pump.com Timing test Start /stop button Control the drive run and stop. Press this button once the drive work status changes once.
- Page 7 Shenchen Pump M6 series used for changing between different external control modes. There are 7 different modes in total. In internal control mode, the external control mode indicators all light off. Only external control start/stop mode: The external control start/stop indicator light is on.
- Page 8 Shenchen Pump M6 series timing time. Press the timing button more than 5sec, the number will occur and flash. Rotate the digital knob to right or left, to increase or decrease the timing time (keep pressing the digital knob to increase or decrease rapidly). The set range is 0.5sec-999sec.
- Page 9 Shenchen Pump M6 series Pin 1, 0-5V: Externally connecting signal positive pole of controlling the ① motor speed, 0-5V connecting wiring port. Pin 2, WK-RUN/STOP: External control start/stop input port (Passive signal: ② Motor runs in normal off status, motor stops in normal on status. Hand-held...
- Page 10 Shenchen Pump M6 series DB15 external control port regular wire sequence as below: Analog Signal 0-5V Pin 1 WK-RUN/STOP Pin 2 WK-DIRECT Pin 3 The Negative Pole of Analog Signal Pin 9 Analog Signal 0-10V Pin 10 Analog Signal 4-20mA...
- Page 11 Isolated External Control Wiring Diagram Pin 12 Pin 13 Positive signal 5-24V Pin 14 External Control Interface for DB15 M6 series pump drive could be equipped with foot pedal and dispenser, if you need please contact us. - 7 -...
- Page 12 Shenchen Pump M6 series Technical Specifications Flow rate <±0.5% Display 3-bit LED accuracy Pure imported Control External control Switch signal keypad Speed range 0.1-600rpm Speed control Digital knob RS232 (Shenchen Speed 0.1rpm (0-100rpm) protocol), Communication resolution 1rpm (100-600rpm) RS485 Modbus RTU protocol AC 220V±10%...
- Page 13 Shenchen Pump M6 series Main Functions and Features Digital knob control speed manually or automatically through external control interface. Timing test function, it is convenient to test the flow rate within specified time. Full speed button with filling and emptying functions.
- Page 14 Shenchen Pump M6 series DZ25-3L Pump Head DZ25-6L Pump Head YZ35 Pump Head - 10...
- Page 15 Shenchen Pump M6 series 7.2 Product Appearance M6-3L + EasyPump Note: For each additional pump head in series, the longitudinal dimension will be increased by 61mm. M6-3L + DZ25-3L Note: For each additional pump head in series, the longitudinal dimension will be increased by 60mm.
- Page 16 Shenchen Pump M6 series M6-6L + DZ25-6L Note: For each additional pump head in series, the longitudinal dimension will be increased by 60mm. M6-12L + YZ35 Note: For each additional pump head in series, the longitudinal dimension will be increase by 78mm.
- Page 17 Shenchen Pump M6 series Maintenance Check the running status of machine before starting it, normal operation can be put into use. Check for leakage, and correct fault which can be appeared. Clean liquid overflowed from the pump in time.
- Page 18 Shenchen Pump M6 series Warranty and After Sales Service We support 3 years warranty for the pumps, subject to the exceptions below. Our company shall not be liable for any loss, damage, or expense directly or indirectly related to or arising out of the use of its products. This warranty does not obligate our company to bear any costs of removal, installation, transportation, or other charges which may arise in connection with a warranty claim.
