3. Select 'DGPS' and set the DGPS mode to 'MB Base', return to the 'VBOX' setup menu.
4. Select 'DGPS RS232 Rate' and ensure that '115200' is selected, return to the 'VBOX' setup menu.
5. Select 'MULTI. TARGET' mode and select 'SUBJECT VEHICLE', return to the 'ADAS' setup menu.
RTK Status Indication
As the Subject Vehicle effectively becomes the Base Station it will not physically go into an RTK lock, therefore the
'DIFF' LED of the Subject VBOX will NOT illuminate. The 'DIFF' LED of the Target VBOX's should gain RTK FIXED
status indicated by the 'DIFF' LED illuminating green.
