Racelogic VBOX User Manual page 6

6. Select 'DGPS' and set the DGPS mode to 'MB Rover', return to the 'VBOX' setup menu.
7. Select 'DGPS RS232 Rate' and select the appropriate settings for your radios, return to the 'VBOX' setup menu.
Note: To ensure that the VBOX receives the DGPS correction signal, the correct RS232 rate must be set. All
Racelogic blue boxed radios use 115200 kbit/s, Satel grey boxed radios use either 19200 kbit/s or 38400 kbit/
s.
8. Return to the main setup menu and select the 'ADAS' option, then select 'MULTI. TARGET' mode.
