Hardware Configuration - Racelogic VBOX User Manual

FCW - Multi-Target (Moving Base)
Multiple Vehicle Targets
This mode facilitates the ability for vehicle separation parameters to be calculated at the Subject vehicle with respect to
two Target vehicles.
This system consists of a VB3iSL-RTK in each Target vehicle and a VB3iSL-RTK in the Subject vehicle.
NOTE: It is not possible to operate in Duplex mode with multiple Target vehicles.
High accuracy of the vehicle separation calculations is made possible by the use of a Moving Base solution.
Moving Base solution removes the need for a fixed Base Station to obtain accurate GPS position, thereby allowing
vehicle separation testing to be carried out in real world environments and without the restrictions of Base Station radio
range.
The Target VBOX (tracked vehicle) will also log the normal GPS data to a .vbo file, so that the files from each VBOX can
be compared in the VBOX Tools Graph screen or VBOX Test Suite Chart screen. This is useful to see the relative
positions.
Configuration of the VBOX's is done through VBOX Manager (RLVBFMAN).

Hardware Configuration

The following diagrams show the recommended hardware configuration for each Vehicle. The items greyed out are not
essential but many customers may find them beneficial.
Connection between the VB3i and computer should be made via USB or Bluetooth to ensure optimum performance.
Please ensure that all vehicle antennas are correctly positioned and connected.
