Setting Up To 24 Contact Points
Media, iframe, embed and object tags are not supported inside of a PDF.
First, connect a ground plane antenna to the VBOX.
Select either 'SUBJECT VEHICLE' or 'TARGET VEHICLE' in the contact points menu. Select 'SET POINTS'.
Using the survey pole, move the antenna to the desired contact point on the vehicle. Ensure there is a fixed RTK
solution and select 'SET POINT'.
If successful, VBOX Manager will display 'POINT 1 SAVED'.
