Video VBOX - Quick start guide

https://racelogic.support/02VBOX_Motorsport/Video_Data_Loggers/Video_VBOX_Range/

As shipped, the Video VBOX can be used straight out of the box:

1. Mount the GPS antenna in the centre of the roof of the vehicle. Keep away from roof bars.

2. Connect the antenna to the Video VBOX.

3. Connect the power connector, it takes about 35s to start.

Page 1 Video VBOX - Quick start guide https://racelogic.support/02VBOX_Motorsport/Video_Data_Loggers/Video_VBOX_Range/ As shipped, the Video VBOX can be used straight out of the box: 1. Mount the GPS antenna in the centre of the roof of the vehicle. Keep away from roof bars. 2. Connect the antenna to the Video VBOX.
Page 2 4. Attach the camera to the windscreen using the forward facing camera mount, keep the camera level using the markings on the camera. 5. Connect the camera to CAM1.
Page 3 AVOUT. Alternatively you can use a Laptop connected via USB to get a live view. 7. Take the car outside and wait for the Green GPS LED to illuminate. 8. Insert the SD card and you are now ready to drive, Video VBOX will start to record Video automatically over 2.5 km/h.
Page 4 Format : FAT32 USB memory sticks If data is to be logged to a USB memory device, the optional RLCAB073 cable is required. Racelogic recommend good quality USB sticks - write speeds above 7MB/s and good USB chip sets are essential.
Page 5 NB: In order to play back the AVI Video files, the XVid Codec pack must also be installed. The installation CD contains the required installation package. Video VBOX Registration So that Racelogic can continue to provide you with notification of the latest software releases, firmware upgrades and to offer technical support, please register your Video VBOX. Please register your unit...
