6
The transceiver has 1 call channel and 50 regular memory
channels plus 1 pair of scan edge memory channels on
each band; each of these can be individually programmed
with the following data. The transceiver has 2 programming
procedures: (1) without checking the overwriting channel
and (2) after selecting the channel to be programmed.
e Operating frequency (p. 12)
e Duplex direction (DUP or DUP —) (p. 16)
e Offset frequency (p. 17)
e Subaudible tone frequency (p. 17)
e Subaudible tone encoder ON/OFF (p. 16)
e Tone squelch ON/OFF*' (p. 39) |
e Skip information*' (p. 29)
*' An optional UT-89 TONE SQUELCH UNIT is necessary.
* Except for the call and scan edge memory channels.
© Memory channel notes
e Memory channels cannot be erased or masked (undis-
played).
e All memory channels are set as skip channels initially.
However, the skip information is erased automatically
when a new frequency is programmed.
MEMORY AND CALL CHANNELS
li Memory channel selection
(D Push the desired band's tuning dial.
@ Push the selected band's [M/CALL] once or twice to
select memory mode.
-" ŒD ° appears.
@ Select the desired memory channel.
Using the tuning dial:
Rotate the selected band's tuning dial to select the
desired memory channel.
Using the [UP]/[DN] switches:
Push [UP] or [DN] to change the memory channel.
- Pushing [UP] or [DN] for more than 0.5 sec. will activate
memory scan. If scan starts, push [UP] or [DN] again to stop
the scan.
|
@ To return to VFO mode, push the selected band's
[V/MHzZ].
Using the optional Mic DTMF remote function (UT-101
DTMF UNIT is required), the memory channel can be
directly selected from a DTMF microphone, e.g. an
optional HM-77, HM-95,* etc. See p. 40 for details.
* The HM-95 is supplied with the U.S.A. version.
