© TONE INDICATORS
e "T" appear while the subaudible tone encoder is in use.
(p. 16)
e "T SQL" appear while the optional tone eater function is
in use. (p. 39) .
e "T SQL ((+))" appear while the optional pocket beep func-
tion is in use. (p. 39)
@ SUB BAND ACCESS INDICATOR
e Appears when the sub band access Tuneton is in use.
(p. 33)
e Flashes while optional external DTMF remote is in use.
(p. 41)
@ MEMORY CHANNEL READOUTS
Show the selected memory channel numbers. (p. 19)
- Only 2 large "L" 's appear while the frequency lock func-
tion is in use. (p. 13)
- A large "C" appears while on a call channel. (p. 23)
- "r1" appears while a duplex scratch pad memory is se-
lected. (p. 24)
- "L1" appears while a simplex scratch pad memory is se-
lected. (p. 24)
- A small "c" appears when VFO mode is selected from the
call channel or a scratch pad memory. (pgs. 23, 24)
- Flashes while in select memory write mode. (p. 20)
PANEL DESCRIPTION 1
© SKIP INDICATORS (p. 29)
Appear when the displayed memory channel is specified
as a skip channel while in memory mode.
© MEMORY INDICATORS (p. 19)
Appear when memory mode is selected.
@ PRIORITY WATCH INDICATORS (p. 32)
Appear while the priority watch is activated; flash while the
watch is paused.
@ S/RF INDICATORS
e Show the relative signal strength while receiving. (p. 14)
e Show the output power selection while transmitting.
(p. 15)
@® BUSY INDICATORS (p. 14)
Appear while a signal is being received or the squelch is
open.
© LOW POWER INDICATOR (p. 15)
Appears while low output power 1 or 2 is selected for the
main band.
© AUDIO MUTE INDICATOR (p. 42)
Appears while the audio mute function is activated in the
optional DTMF remote.
- The optional UT-101 and a DTMF microphone (HM-95, HM-77,
etc.) is required to use the DTMF remote.
© REMOTE INDICATOR (p. 40)
Appears while mic DTMF remote is in standby. Flashes
while the function is activated.
