Positions for Optional I/O Connections and Devices
• Thermo Electric Condenser Connection
Connection for condenser with Thermo Electric cooler.
• Connection for Temperature Control Actuators
Actuator connection for heating and cooling: Thermo Electric element or heating blanket and cooling valve.
• Analog Inputs 0-10V
The four analog inputs can be used as inputs for additional control loops.
A resistor of 500Ω (parallel with the input) can be used to convert a 0-20mA signal to 0-10V.
• Sub-D Connectors for I/O Signals
For lay-out specification of the 37 pins D-sub connector, refer to the section on Analog and Digital I/O
Connections of this Hardware Manual.
Gas Inlets for aeration
The gas inlets (carbon dioxide, oxygen, air and nitrogen) are Quick Connectors for tubing OD = 6 mm.
For information and specifications of the available gas supply hardware, refer to the section on Solenoid
Valve with Tuning Valve and to the section on Mass Flow Controllers.
Required inlet pressure for the gasses:
Required quality of the gasses:
USB-Connectors
Can be used to connect:
• A USB-memory stick, to be used for customizing the IP-address or to export / import data or
configuration files (refer to the Software Reference Manual).
• External devices such as scales, biomass monitors, optical sensors, etc. In case more than 2 USB inputs
need to be connected, a USB-Hub is required.
Non-USB-Connectors
A non-USB connector is used for service purposes.
Network Connector for the Web User Interface
The RJ-45 network connector is used for connection to the Web User Interface / SCADA-application.
In order to comply with the European EMC Standards for "emission" and "immunity", the
maximum length of the Ethernet cable is 30 meters!
3.3

MODULES TO BE MOUNTED INSIDE THE my-CONTROL

The following modules can be mounted inside the my-Control:
Part # Description
Z310211020* Heating Control Module
Z310211030* Heating/Cooling Control Module
Z310211040* Condenser Control Module
Z310213010* Stirrer Control Module Stepper
Z310216020* Control Module for Pumps
Z310216030* Connection Module Micro Valve
Z310216040* Control Module Micro Valve
Z310217050* Redox Control Module
* Additional Modules must be installed by a certified Service Engineer.
Hardware Manual my-Control MiniBio
2 barg.
Instrument grade (dry and free of particles or oil).
Remarks
Supply for Heating Blanket
Supply for Thermo Electric Element
Supply for Thermo Electric Condenser
Supply for Stepper Stirrer Motor
Control Module for 2 Variable Speed Pumps
Connection Plate for 1 Micro Valve
Control Module for 2 Micro Valves
Amplifier Board for a Redox Sensor
THE my-CONTROL
