THE my-CONTROL
3.7

SENSOR INPUT SPECIFICATIONS

The applied sensor input amplifiers have the following specifications.
pH amplifier:
Temperature amplifier:
DO amplifier:
Level amplifier:
The Redox Sensor can be used as an option (the Redox Amplifier Board is required; refer to the
section about modules to be mounted inside the my-Control). It will be connected to the Level 2
sensor connection at the front of the my-Control cabinet. It in fact substitutes the Level 2 sensor.
Redox amplifier:
16
0 pH ... 14 pH
Range:
Accuracy: ± 0.01 pH
R : > 10
in
Resolution: 0.01
Type: Pt-100 (3-wire type)
0 ºC ... +150 ºC
Range:
Accuracy: ± 0.1 ºC
Resolution: 0.1 ºC
Type: Polarographic
0 % ... 100 % (when calibrated with oxygen)
Range:
0 % ... 500 % (when calibrated with air)
Accuracy: ± 0.1 %
Resolution: 0.1 %
Type: On/Off signal
Sensitivity: Software-selectable:
High Sensitivity: Conductivity ≥ 26 µS equals "Contact"
Low Sensitivity: Conductivity ≥ 200 µS equals "Contact"
Refer to section about Level / Foam Sensor Settings in the
Software Reference Manual.
Range: 0 + 2000 mV
Accuracy: ± 1 mV
Resolution: 1 mV
Ω
