- Page 1 GETINGE HS33 USER MANUAL EN - ORIGINAL INSTRUCTION NON PED COUNTRIES P/N: 6034500127 Revision F...
-
Page 3: Table Of Contents
TABLE OF CONTENTS EXPLANATION OF SYMBOLS INTRODUCTION Intended use Warning texts Transport and storage General safety Warranty Life time Verifi cation Validation Copyright Manufacturer Disposal Wrapping material Installation material CONTROL PANEL Control panel layout - Classic Control panel layout - Avanti Pressure and temperature sensors OPERATING INSTRUCTIONS Preparation... -
Page 4: Explanation Of Symbols
EXPLANATION OF SYMBOLS - Read User Manual - Wear hand protection Manufacturer Date of manufacture Serial number Catalogue number Marking of electrical and electronic equipment Caution, hot surface Caution Caution, possibility of electric shock Protective conductor terminal Pressure transmitter Temperature transmitter Validation transmitter - Warning pinch hazard - Marking by which the manufacturer indicates that the product is in conformity with the appli-... -
Page 5: Introduction
HS33 100-liters: Single manual door with Classic display ELECTROMAGNETIC COMPATIBILITY HS33 steam sterilizer complies with the requirements according to the EN 61326-1 with emission limits for class B group 1 equipment and immunity requirements according to industrial electromagnetic environment. -
Page 6: General Safety
NEVER strilize liquids. Hazardous waste and explosive materials must never be sterilized in this sterilizer. Only use loading equipment and accessories especially designed for the Getinge HS33 and specifi ed in the Article list. Technician (service) must provide training for the personnel who is used this sterilizer. -
Page 7: Warranty
For warranty issues, please contact your local Getinge representative. LIFE TIME Expected life time of HS33 sterilizer is 12000 cycles, corresponding to 10 years. VERIFICATION If indicators are used to verify the process, use only certifi ed products, fulfi lling relevant standards. -
Page 8: Manufacturer
MANUFACTURER Getinge IC Production Poland Sp. z o.o. ul. Szkolna 30, 62-064 Plewiska, Poland MDD 93/42/EEC - 0123: TÜV SÜD Product Service GmbH, Ridlerstraße 65, 80339 München, Germany DISPOSAL This product contains electrical and electronic components. The electronics must be handled by an authorized recycling company. -
Page 9: Control Panel
CONTROL PANEL - CLASSIC HS33 DOUBLE DOOR - UNLOADING SIDE HS33 100-LITERS SINGLE MANUAL DOOR CONTROL PANEL LAYOUT Indicator Door locked Door in locked positon Indicator Process running Sterilization process started and running Indicator Process completed Sterilization process is fi nished... -
Page 10: Control Panel Layout - Avanti
CONTROL PANEL - AVANTI DOUBLE DOOR - LOADING SIDE CONTROL PANEL LAYOUT (only automatic door) Indicator Door locked Door in locked positon Indicator Process running STERILIZATION 00:05:15 TEXTILES 134 Sterilization process started and running 00:00:15 01 STERILIZATION Indicator Process completed 3.162 BAR Sterilization process is fi... - Page 11 18 Display unit The display shows the current status, program progress, number of minutes after program start, number of completed cycles and error codes. On the double door version also on the unloading side. 19 Handle (only on sterilizers with manual door function). 20 Emergency stop Press in the switch if an emergency situation arises and the process needs to be interrupted.
-
Page 12: Pressure And Temperature Sensors
PRESSURE AND TEMPERATURE SENSORS ABSOLUTE PRESSURE SENSOR The two absolute pressure sensors are located on the top of the sterilizer. One monitors and controls the process and the second is for the built in printer. Both sensors connect to the left side of the chamber. TEMPERATURE SENSOR TEMPERATURE SENSOR 6 (PT-100 6) The sensor that monitors the sterilization process is a “double sensor”... -
Page 13: Operating Instructions
OPERATING INSTRUCTIONS PREPARATION • Verify if chamber is clean before using the sterilizer (for cleaning instruction see section Periodic Maintenance - page 20). • Verify if door seal did not fell out and is pushed tight into groove at whole circumference. •... -
Page 14: Process Start
PROCESS START • Close and lock the door with the handle. Press the door locking key (7) on sterilizers with automatic door locking, closing door. • Select the appropriate process with the Program selection key (5). For Classic display, use the navigator. •... -
Page 15: Process Description
BOWIE & DICK Only used for running Bowie & Dick chemical test indicators, which met requirements according to EN ISO 11140-4. In our test runs we have used Getinge Assured indicators. Pin code for the user is required (558). LEAKAGE TEST The sterilizer is equipped with a standard leakage test program. -
Page 16: Sterilization Processes
Wrapped/unwrapped instruments, porous and hollow loads. Please note that this cycle is a general-purpose cycle, to be confi gured in accordance with lo- cal requirements and regulations. Getinge assumes no responsibility for the sterilization results of CJD-related goods. Total process time incl. drying... -
Page 17: Test Processes Included
P06 Leak test The sterilization process is sensitive to residual air in the chamber. If the chamber is not leak-tight, sterilization effi ciency may be impaired. Getinge vacuum sterilizers are equipped with a fully automatic leak test process to confi rm leak-tightness of the chamber for the daily use. -
Page 18: Schematic Processes
STANDARD PROCESS Pressure 3150 3000 (134 °C) 2120 (121 °C) 2000 1000 Time 150 150 150 Phases Pre-pulse Sterilization Drying time time vacuum vacuum PROCESS DESCRIPTIONS Description Parameter Range Default Pre-pulse vacuum Pre-pulse positive Sterilization temperature 134-137°C 134 °C P01 Textiles 134 °C Sterilization time 4-10 min 4 min... -
Page 19: Process Interrupted
PROCESS INTERRUPTED IF THE STERILIZER STOPS DURING A PROCESS Avanti: The display shows the symbol magnifi ed and turns completely red. Reset the alarm by pushing the magnifi ed indicator. Classic: The indicator (4) is enlightend. Reset the alarm by pushing the Enter key (12). -
Page 20: Periodic Maintenance
NOTE! Test processes (Bowie&Dick test, Leak test) should be performed as often as customer internal procedure says. HS33 manufacturer recommends performing test processes on a regular basis. END OF DAY ROUTINE 1. Close the door but do not lock. -
Page 21: Annually
WARNING! Do not use water or damp rag to clean the chamber if heated due to the risk of burning injuries! NOTE! When cleaning outside of the sterilizer, be careful not to damage sterilizer’s nameplate with cleaning agents! ANNUALLY OR 1 200 PROCESSES The sterilizer must undergo servicing by a qualifi... -
Page 22: Malfunctions
MALFUNCTIONS GENERAL • External plates must not be removed by anyone other than a technician with documented experience. • Check that the sterilizer is connected to the mains (on sterilizers with automatic doors also to air). • Check that the red indicator lamp is out. •... -
Page 23: Technical Data
Effect, total 5 500 W Effect, steam generator 4 x 900 W Effect, jacket HS33 60-liters: 1 000 W HS33 100-liters: 1 400 W (depending on power supply option) Frequency 50/60 Hz Air supply 5-7 bar dry, fi ltered to 5 microns Heat emission: closed door / open door Approx. -
Page 24: Feed Water
FEED WATER DETERMINANT FEED WATER RESIDUE ON EVAPORATION ≤ 10 mg/l SILICATE ≤ 1 mg/l IRON ≤ 0,2 mg/l CADMIUM ≤ 0,005 mg/l LEAD ≤ 0,05 mg/l REST OF HEAVY METALS EXCEPT IRON, CADMIUM, LEAD ≤ 0,1 mg/l CHLORIDE ≤ 0,5 mg/l PHOSPHATE ≤... -
Page 25: Change Language
CHANGE LANGUAGE CONTROL PANEL - AVANTI “MENU” “SYSTEM MENU” “SETTINGS” PASSWORD: “558” “ENTER” “LOCAL SETTINGS” “LANGUAGE” CHOOSE LANGUAGE “SAVE” “LOGOUT”” CONTROL PANEL - CLASSIC x MENU (10) “SYSTEM MENU” x ENTER (12) PASSWORD: “558” x ENTER (12) “SETTINGS” x ENTER (12) “LOCAL SETTINGS”... -
Page 26: Sales And Service Units Addresses
20 Bendemeer Road, # 06-01/02, Cyberhub Building, Singapore 339914 info.sg@getinge.com ladesh, Malaysia, Philippines, Singapore Getinge Sverige AB Sweden Ekebergsvägen 26, P.O. Box 69, 305 75 Getinge info@getinge.com Getinge France SAS France 7 Avenue du Canada, 91940 Les Ulis, getinge.france@getinge.com Getinge Sterilization AB Sweden Ekebergsvägen 26, Box 69305 05 Getinge... -
Page 27: Attachments
Getinge is a global provider of innovative solutions for operating rooms, intensive care units, sterilization departments and for life science companies and institutions. Based on our fi rsthand experience and close partnerships with clinical experts,healthcare professionals and medtech specialists, we are improving the...
