Internal modules: the firmware of
each internal module
installed) can be seen by accessing
to the configuration
(paragraph 2.3 - [J], paragraph 3.2 -
[K]).
The address and the firmware
revision of the detected modules
are shown in the proper section [C].
4.8

Registration of the control panel to Inim Cloud

The registration of a control panel is an operation that allows its accessibility to all Inim Cloud service users. It is therefore
necessary that the registration is carried out first by the installer, registered with the Inim Cloud service, so that later users
can add the already registered control panel to their own account.
1. Access the programming phase of the control panel (paragraph 2.1) and then press the Network button on the
menu that appears on the screen.
2. Enable the "Cloud enabled" option.
3. Access the "Enroll" section via the button that appears below.
4. Enter the 8-digit ID-installer number contained in the confirmation email received during registration to the Cloud as
an installer.
In this section you can activate the "Installer Property" option. If activated, the installer reserves the management of
accesses to the system by the Cloud. If not activated, this property is assigned to the first user enrolled
5. Press the Enroll button. The control panel will carry out the registration of the control panel on the Cloud and the
display will show the "WAIT" message.
If the control panel date/time differs by more than 15 minutes from the exact date/time, the registration process may
result negative.
6. The screen will show the outcome of the procedure via one of the following messages:
• "Account created!": the control panel has been successfully registered to Cloud
• "Communicat.Error": generic communication error.
The possible causes may be:
- no Internet connection
- date of manufacture of the control panel is earlier than dd/mm/yyyy
- date/time of control panel different, ahead of or behind the exact date/time by more than 15 minutes
• "Already enrolled": the control panel is already registered to Cloud
• "Panel notEnabled": the control panel cannot be registered to Cloud.
28
(already
menu
*
*
*
Touch to set address and acquire
C
L: 3
N.01 FW:1.0.0. C
C
N.01 FW:1.0.0.
N.01 FW:1.0.0.
C
N.04 FW:1.0.0.
C
N.05 FW:1.0.0.
C
Generic configuration of the control panel
Fire detection and extinguishing system
Network Address: 2
Set
Esc
01/01/2022
18:23
