Configuration manual
Configuration of the emergency voice system
Once the installation and cabling procedures have been completed (refer to the Installation Manual of the Previdia Ultra
system) the system is ready for first startup.
In the case of first start-up, the selection of the control panel languages is requested (see paragraph 4.5).
The control panel screen will be as follows:
Buttons to access the
[A]
events logs, system
status and programming.
Status bar (always
present) shows essential
[B]
information regarding
the system.
Button for changing the
language of the control
[C]
panel, if a secondary
language is provided
Configuration status
[D]
icon (system
configuration and faults)
In this condition the control panel has no acquired configuration, all the modules connected to the CAN drive bar or
front plate have the same address and are not included in the configuration.
The configuration status icon on the status bar indicates a fault condition, due to the fact that modules have been
detected but are not present in the configuration saved in the memory.
In order to configure the control panel it is necessary to work through the following procedure:
1. Access programming (paragraph 3.1)
2. Set the IP network address (paragraph 3.6)
3. Access the configuration menu (paragraph 3.2)
4. Assign addresses to the system modules (paragraph 3.3)
5. Set the defined configuration (paragraph 4.3)
6. Check eventual signalling and search for faults (paragraph 4.4)
7. Set the date and time (paragraph 4.6)
Note:
Once the configuration operations have been completed correctly, the control panel will be ready to operate.
At this point it is necessary to proceed with any configuration data modification operations to enter significant
descriptions for the various elements of the system, and define sequences of particular activations, etc.
Refer to the Programming manual.
Configuration of the emergency voice system
B
C
L: 1
Chapter 3
Log
System Status
Programming
Audio Settings
01/01/2022
D
18:23
A
15
