Configuration manual

• Verification time (s), if an input device has the alarm verification option enabled, the maximum verification time is 30

minutes (EN 54-2 - clause 7.12.1 [c]).

• Lock reset time after released (min), the maximum time is 30 minutes (EN 12094-1:2003 - clause 4.12.2).

• Pre-extinction time on automatic/manual activation, the maximum time is 60 seconds (EN 12094-1:2003 - clause

4.17.2).

• Valve ON time, the maximum time is 300 seconds (EN 12094-1:2003 - clause 4.21).

Refer to the Previdia/STUDIO software programming manual for more details about the parameters listed above.
