INIM Electronics PREVIDIA ULTRA Manual page 20

[A] Module layout
Information on the
[B]
module
Button to access the
[C]
settings
Button to access the
[D]
PTT microphone
configuration
Button to access the
[E]
TCP/IP settings
Button to access the
[F] SD micro card
functions
Buttons for setting the
[G]
manual emergency
procedures
Buttons for setting
[H]
evacuation and alert
messages
Buttons to carry out
[I]
setting changes or to
exit without saving
Tapping on the button with the settings icon in the centre accesses a screen for the programming of
the following voice-emergency control panel parameters.
• description of the control panel
• number of audio zones in the system
• number of audio sectors in the system
• buzzer enablement
• PTT microphone supervision
Option that if enabled, generates a fault in the event of disconnection of the PTT microphone.
• possibility to reactivate or not the emergency messages, when a new activation request is received after the system
has been silenced following a first emergency
• possibility to change the playback volumes of voice and emergency messages with control panel not in programming
status (see paragraph 3.6.2).
Tapping on the button corresponding to the PTT microphone icon accesses a screen for setting the
audio zones on which the PTT microphone signal will be transmitted by default during the manual
emergency procedure (see Manual emergency procedure).
Tapping on the button corresponding to the Ethernet network icon accesses a screen for programming
the TCP/IP connection parameters.
Tapping on the button with the microSD card icon accesses several functions available thanks to the
card, if present (paragraph 3.6.1).
Tapping on the button corresponding to the Manual emergency icon accesses a screen where it is
possible to select whether or not to display the Help page in the Manual emergency procedure.
In the case that you choose not to display it will be possible to configure the Wizard parameters:
• parts of the system to select: you can define how the user can select the parts of the system to send in an emergency
(all, audio zones, sectors or a combination of them)
• preset messages: you can define whether the user can select the alert warning call and the actual emergency
message, or whether the default messages will be used
By tapping on the buttons with the "Evacuation" and "Alert" icons it is possible to set the audio zones on
which the respective evacuation and alert messages will be transmitted by default during manual
emergency procedure .
20
C
D
E
L: 3
Fire detection and extinguishing system
H
A
G
Configuration of the emergency voice system
Display Board
B
SN: SNSNSNSSN
FW: 1.1.1
BUILD: bbbbbb
Set
I
F
Esc
01/01/2022
18:23
