[A] Module layout
Information on the
[B]
module
Button to access the
[C]
microphone bases of
line A/B
Information regarding
[D]
the microphone bases
of line A/B
Button to access the
[E]
messages saved to
the flash memory
Button to access the
[F]
messages saved to
the micro SD card
Buttons to carry out
[G] setting changes or to
exit without saving
Tapping on the buttons that access the configuration of the voice messages in the memory of the
IFAMEVAC module or the micro SD card, if present, will display the list of available messages.
By selecting a message from the list it is possible to set the following parameters for playback purposes:
• number of repetitions
• pause between two repetitions
• priority
• message to be associated, to be used to attract the attention of those present in the building
In correspondence with the icons of the connection terminals of "MUSIC 1", "MUSIC 2", "A PAGERS", "B
PAGERS" are buttons that allow you to program, for the connected audio sources concerned, the
following parameters:
• description
• volume and treble/mid /bass balance
• priority
To the "AUX1" and "AUX2" inputs, furthermore, you can associate:
• an alert warning message
• the audio zones on which to execute the communication, in the case of the "PR" input
In correspondence with the icon pertaining to the "HANDSET" input, it is possible to program the
parameters of the PTT microphone and telephone calls:
• description
• volume and treble/mid/bass balance
• priority (for the PTT microphone only)
• an alert warning message (for the PTT microphone only)
In correspondence with the LAN network terminal icon, it is possible to access the programming of the
TCP/IP connection parameters of the module and the setup of the IAS server. If this is present, it will be
possible to configure the following parameters by pressing the appropriate button:
• priority
• reception and transmission ports for UDP communication
• list of four IP addresses from which the server can receive commands and audio streams (optional, active only if the
"IP Check" checkbox is selected)
Tapping on none of the access buttons to the configuration of the microphone bases displays a pop-
up to start the enrolling of the bases on a line or to select one and configure the following parameters:
• description
• priority of non-emergency communications
• priority of emergency communications (if applicable for the selected base model)
18
0 Line A Pagers
E
1mA
26.1V
26.2V
F
1mA
0 Line B Pagers
L: 3
Fire detection and extinguishing system
C
Line A Pagers
D
A
D
C
Line B Pagers
Configuration of the emergency voice system
Audio Matrix
B
SN: SNSNSNSSN
FW: 1.1.1
Set
G
Esc
01/01/2022
18:23
Line A/B bases
